The Ricoh XR-M SLR

 By the mid-1980s, camera manufacturers were moving towards more plastic in the bodies of 35mm SLR cameras. Point and shoots had already achieved this, as the ABS plastic was found to be excellent for camera bodies.  The consumer-level SLRs such as the Canon T50 and T70, Nikon N2000, and Pentax P30 featured plastic bodies with internal metal chassis, or in some cases, more ABS plastic.  Ricoh introduced its XR-M SLR in 1987, and this manual-focus auto-wind camera features design elements that remind me of both the Canon T70 and a  Minolta Maxxum 7000.

The Ricoh XR-M has a bunch of features that place this camera as being quite advanced and I am surprised that it didn't get more attention.

Fairly good control layout!  Looks much like a 1990s SLR

There is an optical frame counter - no IR for you.

clean design

Features and Specifications
  • Top-deck LCD display panel
  • Program modes - P, A, M, S
  • ISO setting via DX or manually entered from 12-6400
  • Auto film loading, film auto-advance and rewind
  • film loaded window
  • Viewfinder with the following functions visible:
  • AE lock indicator
  • Subtractive film counter
  • Exposure Compensation
  • Over/under exposure indicator
  • Shutter speed
  • Program mode (PASM)
  • Shutter speed
  • Flash ready
  • Aperture
  • Auto backlight indicator
  • Spot metering indicator
  • Averaged metering indicator
  • Fill Flash indicator

Obviously presaging cameras such as a Nikon N50, based upon the above specs!

  • Viewfinder - 91% coverage, the XR-M has an angled split image focus spot and microprism focus collar, as well as a matte screen to aid in focus.  In use, I found the split image focus spot to be very easy to see and use.
  • Depth of Field Preview button!
  • Self-timer with variable time settings
  • Programmed flash photography with Ricoh Speedlights
  • TV mode - for photographing TV screen, set at 1/30 sec.
  • Center-weighted metering and spot metering modes
  • Interval timer- set to fire shutter 1 sec to 1 hour for time-lapse
  • Single frame shooting to continuous, as well as multiple exposures
  • AE lock!
  • Exposure Compensation +/- 4 stops in 1/3 stop increments
  • Bulb setting
  • Left hand-shutter release can be programmed
  • Power- Requires 4 AA cells
  • Shutter - vertical focal plane shutter 30 sec - 1/2000 sec, plus B- 1 sec to 1 hour
  • Lens mount - Ricoh system R-K mount.  You can use other K-mount lenses with this camera, but I do not think all will work in Program mode.
  • Tripod socket
  • Weight with 50mm lens and 4 AA cells is 1 lb 11 oz.
Have yet to test out the flash and the zoom lens.

Available accessories:
  • Super Data Back 4
  • Data back 3
  • Interchangeable viewfinder screens
  • Speedlight PX
  • XR Speedlight 300P, as well as other speedlights

Overall, a staggering amount of options and control for a 1987 off-brand SLR.

This camera came to me with the control button cover missing. That's just a small piece of plastic that covers the 4 orange control button on the left top of the camera.  You really do need the the manual to get the most out of this camera. However, once you figure out the system, it's pretty easy to use in most of its operation.

I found that the right-hand grip (which contains the 4 AA cells, much like a Minolta Maxxum 7000) makes the camera very easy to hold, with my index finger falling directly over the shutter button.  There is no screw-in cable release, but a small remote socket on the rear of the body, which looks a lot like that of a Canon rebel's simple remote socket.

The interval timer is pretty cool. I set it to shoot a frame every two seconds and had fun standing in front of the camera and letting it fire away. It went through a 24 exposure roll of Kentmere 400 in less than a minute.

I took the camera out to the River Arts District of Asheville on a nice day in late October and shot a couple of rolls of film.  The auto-advance of the film combined with shooting it in P mode, made it act like a P&S SLR - much like a Canon AE-1P, but with auto-wind. I really like the way in feels in the hand, and it was easy to shoot with.

I'm not sure why this camera hasn't gotten more love.  Maybe it was just a bit ahead of its time, and maybe if it had autofocus, it might have been a bigger deal. In any event, I found it very easy to shoot with, though perhaps at the time it came out, not having dials and traditional SLR-style controls was considered to be too gimmicky.  The controls certainly would have been right there with 1990s cameras, though.

I say that the camera reminds me a lot of the Canon T-70, and it really does have a similar look and feel to that camera, right down to the gray plastic body.  However, the Ricoh XR-M has far more modes and control options than the Canon T-70. Perhaps if the camera had a Pentax logo on it, it may have fared better.  It certainly seems better made than a lot of the Pentax plastic-bodied SLRs from that era.

This camera came with the 35-70 zoom as well as the 50mm f/2 Rikenon lens (which I used), as well as the Ricoh XR 300P speedlight (which I did not use).  The overall package is one that would be quite usable by any photographer.

Now some sample photos, of course! These are all on Tmax 100.
